Selected product:
Art. no: 33022400
Designation: BETEX MF Generator 3.0 - 22kW 400V
Request for information

The BETEX MF-GENERATOR 3.0 has been replaced by a new and improved model.



The BETEX MF-GENERATOR3.1 features several technical upgrades and additional functionalities that contribute to more efficient operation.



View the MF-GENERATOR3.1 22kW >

For current stock, email our sales department.

Product specifications

Product
Request for information
Number
Certification
Forced air cooling
Power kW
Frequency reach kHz
Voltage/Amp
Frequency Hz
Temperature measurement
Max. temperature
Accuracy
Inductor recognition
Temperature sensor (2 pieces)
Extra thermo couple input
Dimensions LxWxH mm
Weight kg
Display inch
Heating curve in display
Delta T
Setpoint power
Setpoint temperature
Setpoint temperature curve
Setpoint timer
Select operating mode
Digital readings temperature
Digital readings time
Digital readings power
Digital readings frequency
USB connection
Network connection
Heat log
Signalling by operational state
Signalling by error message
Signalling by end heating cycle
Signal tower
BETEX MF Generator 3.0 - 22kW 400V
33022400
CE + UKCA
Yes
22
10-25
3~400V/32A
50/60
For type K thermocouple
300 °C / 572 °F
± 38.2°F / ± 3.5°C
Yes
Yes, for max 300°C / 572°F
Yes
600x300x600
46
7
Yes
Yes
Via touchscreen
Via touchscreen
Yes
Via touchscreen
Via touchscreen
Setpoint and actual value on touchscreen
Setpoint and actual value on touchscreen
Actual value on touchscreen
Acutal value on touchscreen
Yes
Yes
Yes
Via touchscreen
Acoustic signal
Acoustic signal
Optional
BETEX MF Generator 3.0 - 22kW 450V
33022450
CE + UKCA
Yes
22
10-25
3~450V/30A
50/60
For type K thermocouple
300 °C / 572 °F
± 38.2°F / ± 3.5°C
Yes
Yes, for max 300°C / 572°F
Yes
600x300x600
46
7
Yes
Yes
Via touchscreen
Via touchscreen
Yes
Via touchscreen
Via touchscreen
Setpoint and actual value on touchscreen
Setpoint and actual value on touchscreen
Actual value on touchscreen
Acutal value on touchscreen
Yes
Yes
Yes
Via touchscreen
Acoustic signal
Acoustic signal
Optional
BETEX MF Generator 3.0 - 22kW 500V
33022500
CE + UKCA
Yes
22
10-25
3~500V/28A
50/60
For type K thermocouple
300 °C / 572 °F
± 38.2°F / ± 3.5°C
Yes
Yes, for max 300°C / 572°F
Yes
600x300x600
46
7
Yes
Yes
Via touchscreen
Via touchscreen
Yes
Via touchscreen
Via touchscreen
Setpoint and actual value on touchscreen
Setpoint and actual value on touchscreen
Actual value on touchscreen
Acutal value on touchscreen
Yes
Yes
Yes
Via touchscreen
Acoustic signal
Acoustic signal
Optional
BETEX MF Generator 3.0 - 22kW 600V
33022600
-
Yes
22
10-25
3~600V/23A
50/60
For type K thermocouple
300 °C / 572 °F
± 38.2°F / ± 3.5°C
Yes
Yes, for max 300°C / 572°F
Yes
600x300x600
46
7
Yes
Yes
Via touchscreen
Via touchscreen
Yes
Via touchscreen
Via touchscreen
Setpoint and actual value on touchscreen
Setpoint and actual value on touchscreen
Actual value on touchscreen
Acutal value on touchscreen
Yes
Yes
Yes
Via touchscreen
Acoustic signal
Acoustic signal
Optional

Accessories

Magnetic temperature sensors
Max. temperature
Length m
270581 - BETEX Clamp temperature sensor
240 °C / 464 °F
1.1
270584 - BETEX Magnetic temperature sensor green 350°C - 3.5m
350 °C / 662 °F
3.5
270588 - BETEX Magnetic temperature sensor red 350°C - 3.5m
350 °C / 662 °F
3.5
BETEX MF flexible inductors 22kW
Length m
Max. temperature
Cable Ø mm
Min. winding diameter mm
Short use
Weight kg
BETEX Flexible Inductor - 22kW - 180C - Short Usage (2)
15
180 °C / 356 °F
12
75
Yes
5
BETEX Flexible Inductor - 22kW - 180C - Short Usage (2)
20
180 °C / 356 °F
12
75
Yes
7
BETEX Flexible Inductor - 22kW - 180C - Short Usage (2)
25
180 °C / 356 °F
12
75
Yes
9
BETEX Flexible Inductor - 22kW - 180C - Short Usage (2)
30
180 °C / 356 °F
12
75
Yes
11
BETEX Flexible inductor - 22kW - 180C
15
180 °C / 356 °F
15
100
-
7
BETEX Flexible inductor - 22kW - 180C
20
180 °C / 356 °F
15
100
-
9
BETEX Flexible inductor - 22kW - 180C
25
180 °C / 356 °F
15
100
-
11
BETEX Flexible inductor - 22kW - 180C
30
180 °C / 356 °F
15
100
-
14
BETEX Flexible inductor - 22kW - 180C
35
180 °C / 356 °F
15
100
-
18
BETEX Flexible Inductor - 22kW - 300C (2)
15
300 °C / 572 °F
20
120
-
9
BETEX Flexible Inductor - 22kW - 300C (2)
20
300 °C / 572 °F
20
120
-
12
BETEX Flexible Inductor - 22kW - 300C (2)
25
300 °C / 572 °F
20
120
-
16
BETEX Flexible Inductor - 22kW - 300C (2)
30
300 °C / 572 °F
20
120
-
18
BETEX MF connection set
Length m
Upto max. power kW
Inductor recognition
Weight kg
BETEX Connection set - 22kW 3m
3
22
No
3.7
BETEX Connection set - 22kW 3m
3
22
Yes
4.9
BETEX MF Magnetic holders
Weight kg
350200975 - Magnetic Clamps - Set of 5 pieces
1.4
BETEX MF signal tower
Weight kg
BETEX MF-GENERATOR - Signal Tower - V1
0.31
Gloves
Max. temperature
279998 - BETEX Gloves white 250°C
250 °C / 482 °F
279992 - BETEX Gloves - 300°C
300 °C / 572 °F
